900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

Name: 900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band
Brand: ATNJ
Price: 100 USD

Quality 900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band for sale

Brand Name : ATNJ

Model Number : JS-DB900/1800

Certification : CE,ROHS，CCC，TUV,BV， ISO

Place of Origin : China

MOQ : 5Pcs

Price : USD+100---120+kit

Payment Terms : T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability : 1000+unit+per day.

Delivery Time : 2 work days

Packaging Details : Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(53x49x42cm)

900MHz Frequency Range : 890-915MHz / 935-960MHz

1800MHz Frequency Range : 1710-1785MHz / 1805-1880MHz

Color : Gold,Black,White,Customized

RF Connect Type : N/Female

Packing size : 52x21x16cm

Products Type : Signal Amplifier 4G, gooster

Contact Now

900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

GSM LTE Signal Booster 900/1800MHz Metal Cellular Dual Band Repeater Amplifier

Selling Point

LCD Display.

Shows signal strength indoors and outdoors, which is a huge help when setting up. If errors occur, messages appear on the display explaining the reason and suggesting solutions. In addition, installation tips are offered.

Sleep mode.

If you are not using a mobile connection (calling or mobile internet), the amplifier will go into power-saving mode and automatically return to operating mode as soon as you start using the phone.

Automatic control.

The amplifier automatically adjusts the input signal and gain depending on the signal reception conditions in your home.

Technical Specifications

Specifications		Parameters
Frequency Range (Customers to Choose)	Uplink	890-915MHz,1710-1785MHz
	Downlink	935-960MHz,1805-1880MHz
Frequency Bandwidth		25MHz&75MHz
Gain		70dB
Automatic gain control (Step Attenuation)		31dB @ 1dB/ Step
Auto Gain Control		20dB Min.
Output Power(Customers to Choose)		20dBm
Spurious Emission		≤ -15dBm/30kHz
		9kHz~1GHz: ≤ -36dBm/30kHz
		1GHz~12.75GHz: ≤ -30dBm/30kHz
Inter-Modulation Attenuation ACPR		≤ -40dBc / 30kHz (measured under rated output power)
In-band Ripple		≤ 3dB
VSWR		<=2
I/O Impedance		50 Ω
Noise Figure		≤ 5dB
System Delay		≤ 5μs
Operating Temperature		Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C
Power Supply		AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
Dimensions		16513040 (mm)
Weight		≤0.8 kg(Net)
Alarm Monitoring System		Alarm for uplink self-oscillation
Indication LED		Power supply

Further detail pls click here for downloading the products specification:

900+1800MHz A032 mobile signal repeater.pdf

Product Description

900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

Packaging Including:

1. GSM 900MHz DCS 1800MHz Dual Band Booster

2. Power adapter

3. Outdoor Log-periodic antenna

4. Indoor Ceiling antenna

5. 5 meters cable

6. 20 meters cable

900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

Installation Approaches

1. Fix up outdoor antenna reception on housetop and point to signal tower;

2. Connect outdoor antenna to “outdoor” port in repeater nachine through cable;

3. Connect indoor antenna(s) to “indoor” port in repeater machinethrough cable also;

4. Plug power adaptor into AC power socket and finish installation.

900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

The repeater makes the signal stronger in places with poor signal coverage such as:

1) Underground areas: basements, parking lots, tunnels;

2) Other places where cellular signal is shielded by metal or concrete walls: offices, supermarkets, cinemas, hotels;

3) Places distant from the BTS like private houses.

900MHz 1800MHz GSM LTE Signal Booster Automatic Control Dual Band

FAQ:

1. Are you trading company or manufacturer ? Could I use our own logo and label?

We are factory, with trading service. We provide OEM/OEM service.

2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

3. Is it easy to set up your items?

Yes. We have a user manual and support technical support 24/7.

4. What's your device lifespan?
Normally our device can be used 5-10 years.

5. How many square meters can be covered?
For different models, the covered square meters are different.

6. How about gain and output power of your device?
Different models, gain and output power are different,for more details, please contact us.
